Product name ：Zmotion IDE "RTSys" User Manual
Zmotion develops one own free IDE development platform RTSys.
Download Add.: https://www.zmotionglobal.com/pro_info_282.html
Development & Simulation: RTSys + its simulator ZMCSim
Development Products: ZMC, ECI, PCI, VPLC......
Development Languages:
[RTBasic + RTPlc + RTHmi]
[PC Programming Language with same set of API Function: C#, C++, Labview, VB, Python, ect.]
Software Languages: Chinese & English & Your Language
RTSys supports 3 programming methods: Basic, PLC, HMI.
Support multiple Basic tasks (run at the same time).
No controller, it supports simulation, to do debugging, developing, etc.
There is one "SCOPE" (oscilloscope) funtion to capture data waveform, then to analyze corresponding program.
For online debugging, support "Manual" (manual motion), "Register" (set and read data), "IO", "AIO", etc.
Support "breakpoint setting" and other single-step program debugging.
Support "pnline command & output", "state checking", etc.
Easy to Use, Quick to Develop.
| Name | Version No | Format | Size | Download |
|---|---|---|---|---|
| RTSys User Manual V1.5.0 | V1.5.0 | 5.77MB | Download |
